This new lightweight hybrid hermetic connector offers weight savings up to 68% over similar stainless steel construction.
BTC Electronic Components (BTC – Wake Forest, NC) announced that it’s offering new lightweight aluminum hybrid hermetic connectors from Hermetic Seal Corporation (HSC). HSC – part of Ametek/HCC Interconnect Technologies – is now producing in volume, a lightweight hybrid hermetic connector with weight savings up to 68% over similar stainless steel construction. By combining an aluminum shell, stainless steel inserts and 52 alloy pins provides a true glass-to-metal seal (GTMS) connector.
Current configurations include: MIL-DTL-5015 Class “H” and MIL-DTL-38999 Rev “J”. Other configurations are available based upon specific requirements.
This connector is a good fit for designers looking for weight savings. To date the main application has been on the F-35.
Other notable features about this connector:
- Testing per MIL-H-28719, Type I; MIL-DTL-5015, Class H Series 1 & 2: and MIL-DTL-38999 Series III Rev “J” per Method 202
- Insert Arrangements per MIL-STD-1651/1560
- 168 Hour SO2 Tested per ASTM G85
- -40 to + 275 F Operating (-65 to +275 F Non-Operating)
