| Temperature | -55 to 150 ºC |
|---|---|
| Nom. Velocity of Propagation | 62 % |
| Nom. Attenuation @ 100 MHz per 100 ft. | 13.4 dB |
| Nom. Attenuation @ 200 MHz per 100 ft. | 19.02 dB |
| Capacitance | 15.76 pF/ft |
| Flammability | Shall Pass FAA FAR 25.853/869 |
| Packaging | To be supplied on bulk reels, random factory lengths |
| Conductor | 30 AWG 7/38 High Strength Silver Plated Alloy |
|---|---|
| Nom. Conductor Diameter | 0.012 in |
| Insulation | Extruded ETFE Colors - White and Blue |
| Nom. Insulation Diameter | 0.380 in |
| Cable Type | Planetary Twist Per M17 for Balanced Line |
| Nom. Cable Diameter | 0.076 in |
| Outer Shield | 38 AWG Silver Plated Copper Braid Having 90% Minimum Optimum Coverage |
| Nom. Outer Shield Diameter | 0.095 in |
| Outer Jacket Material | Extruded ETFE 0.010 Inch Wall - Color Natural |
| Nom. Outer Jacket Diameter | 0.118 in |
